Carbon Film Resistor 1/4W 5% Axial Through Hole, Pack of 10
4 in stock
Carbon film resistor, 1/4W (0.25W), 5% tolerance, axial through-hole, pack of 10. Ideal for general-purpose electronic circuits.
Shipping, returns, and payments
Carbon Film Resistor 1/4W
Reliable carbon film resistors for general-purpose electronic circuits. This pack includes 10 pieces with 1/4W (0.25W) power rating and 5% tolerance.
Specifications:
- Type: Carbon Film Resistor
- Power Rating: 0.25W (1/4W)
- Tolerance: 5%
- Form Factor: Axial
- Mounting Type: Through Hole
- Quantity Per Pack: 10
Specifications
| Brand | Generic |
|---|---|
| Part Name | Carbon Film Resistor |
| Power Rating | 0.25W |
| Resistance Tolerance | 5% |
| Quantity Per Pack | 10 |
| Temperature Coefficient | ±200 ppm/°C |
| Maximum Working Voltage | 250V |
| Body Length | 6.0 mm |
| Body Diameter | 2.3 mm |
| Lead Diameter | 0.6 mm |
| Lead Length | 25.0 mm |
| Operating Temperature Range | -55°C to +155°C |
| Storage Temperature Range | -55°C to +155°C |
| Dielectric Withstanding Voltage | 500V |
| Insulation Resistance | >1000 MΩ |
| Packaging Type | Loose |
| Lead Material | Tinned Copper |
| RoHS Compliance | Yes |
| Mounting Type | Through Hole |
| Passive/Active | Passive |
| Form Factor | Axial |
| Chemical Composition | Carbon Film |
| Flame Retardant Coating | Yes |
| Minimum Resistance Range | 1Ω (Varies by set) |
| Maximum Resistance Range | 10MΩ (Varies by set) |
| Economical Item | Yes |
| Low Noise | Yes |
| Widely Used in | Consumer Electronics |
| Application Areas | General Purpose |
| Resistance | 100k Ohm, 33k Ohm, 47k Ohm, 4.7k Ohm, 10k Ohm, 1 Meg Ohm, 12k Ohm, 56k Ohm, 270 Ohm, 300 Ohm, 330 Ohm, 360 Ohm, 390 Ohm, 430 Ohm, 470 Ohm, 510 Ohm, 560 Ohm, 620 Ohm, 680 Ohm, 750 Ohm, 820 Ohm, 910 Ohm, 1.3k Ohm, 1.5k Ohm, 1.6k Ohm, 1.8k Ohm, 2k Ohm, 2.2k Ohm, 2.4k Ohm, 2.7k Ohm, 3k Ohm, 3.3k Ohm, 3.6k Ohm, 3.9k Ohm, 4.3k Ohm, 5.1k Ohm, 5.6k Ohm, 6.2k Ohm, 6.8k Ohm, 7.5k Ohm, 8.2k Ohm, 9.1k Ohm, 15k Ohm, 18k Ohm, 20k Ohm, 22k Ohm, 24k Ohm, 27k Ohm, 30k Ohm, 36k Ohm, 43k Ohm, 51k Ohm, 62k Ohm, 68k Ohm, 75k Ohm, 82k Ohm, 91k Ohm, 120k Ohm, 150k Ohm, 180k Ohm, 200k Ohm, 220k Ohm, 240k Ohm, 270k Ohm, 300k Ohm, 330k Ohm, 360k Ohm, 390k Ohm, 430k Ohm, 470k Ohm, 510k Ohm, 750k Ohm, 820k Ohm, 910k Ohm, 1.5 Meg Ohm, 2 Meg Ohm, 3 Meg Ohm, 11k Ohm, 2.2 Meg Ohm, 2.4 Meg Ohm, 3.9 Meg Ohm, 3.3 Meg Ohm, 1k Ohm, 13k Ohm, 16k Ohm, 39k Ohm, 110k Ohm, 130k Ohm, 160k Ohm, 560k Ohm, 680k Ohm, 1.2 Meg Ohm, 1.6 Meg Ohm, 1.8 Meg Ohm, 2.7 Meg Ohm, 3.6 Meg Ohm, 4.3 Meg Ohm, 4.7 Meg Ohm, 5.1 Meg Ohm, 5.6 Meg Ohm, 6.2 Meg Ohm, 6.8 Meg Ohm, 7.5 Meg Ohm, 8.2 Meg Ohm, 9.1 Meg Ohm, 10 Meg Ohm, 1.2k Ohm, 5.1 Ohm, 11 Meg Ohm |
