5PCS L7815CV | 3 Pin Positive Voltage Regulator | 15V 1.5A TO-220
1 in stock
1 in stock
L7815CV Voltage Regulator
The L7815CV is a robust 15V 1.5A positive voltage regulator from STMicroelectronics. Ideal for various applications, it offers excellent performance and reliability in the standard TO-220 package. Designed to meet the demanding needs of engineers, this component ensures stable voltage delivery for your circuits.
- Output Voltage: 15V
- Output Current: 1.5A
- Package Type: TO-220
- High Efficiency: Low dropout voltage
- Ideal Use Case: Power management in electronic circuits
Ensure stable power for your designs with the L7815CV. Order now to enhance your project’s performance and reliability.
Shipping, returns, and payments
5PCS L7815CV | 3 Pin Positive Voltage Regulator | 15V 1.5A TO-220 | US Ship
Product Details:
Enhance your electronic projects with these L7815CV voltage regulators, expertly designed for consistent and reliable 15V output. Perfect for power management in circuit designs, these regulators are an essential component for maintaining stability in electrical engineering applications.
Specifications:
- ✅ Quantity: 5 Pieces
- ✅ Output Voltage: 15V
- ✅ Output Current: 1.5A
- ✅ Package: TO-220
- ✅ Polarity: Positive Voltage Regulator
- ✅ US Shipping: Available
Features & Benefits:
- ✔️ Provides stable voltage regulation for smooth circuit operation
- ✔️ 1.5A current output for efficient power handling
- ✔️ Robust TO-220 package for heat dissipation
- ✔️ Ideal for power supply designs and other industrial applications
- ✔️ High reliability in diverse temperature environments
© 2025 Fahmah Jackson LLC. All Rights Reserved.
Specifications
| Brand | Unbranded |
|---|---|
| Line Regulation | 0.02%/V |
| Over Temperature Protection | Yes |
| Short Circuit Protection | Yes |
| Noise | 90µV |
| Polarity | Positive |
| Packaging | Tape and Reel or Tube |
| Thermal Resistance Junction to Case | 5°C/W |
| Minimum Input Voltage | 17V |
| Adjustability | Not Adjustable |
| Maximum Operating Frequency | N/A |
| Temperature Coefficient | 0.7mV/°C |
| Output Type | Fixed |
| Load Regulation | 0.1% |
| Quiescent Current | 6mA |
| Part Number | L7815CV |
| Manufacturer | STMicroelectronics |
| Mounting Type | Through Hole |
| Weight | 1.9g |
| Lead Free Status | RoHS Compliant |
| Operating Temperature Range | -40°C to 125°C |
| Power Dissipation | 15W |
| Maximum Input Voltage | 35V |
| Output Voltage Tolerance | ±4% |
| Dropout Voltage | 2V |
| Number of Pins | 3 |
| Output Current | 1.5A |
| Output Voltage | 15V |
| Function | Positive Voltage Regulator |
| Package Type | TO-220 |
