50pcs SS9013 S9013 NPN Transistor TO-92 20V 500mA 625mW
3 in stock
3 in stock
50pcs SS9013 NPN Transistors
Unleash the power of precision with our 50-pack SS9013 NPN Transistors. Designed for high efficiency and reliability, these transistors are essential for your electronic projects.
- Collector-Emitter Voltage: 20V
- Collector Current: 500mA
- Power Dissipation: 625mW
- Package Type: TO-92
- Application: Amplification and Switching
Enhance your circuit designs with our SS9013 transistors, perfect for both professional and hobbyist projects. Order now and advance your electronic applications!
Shipping, returns, and payments
50pcs SS9013 S9013 NPN Transistor TO-92 20V 500mA 625mW | US Ship
Product Details:
Optimize your electronic designs with these high-performance SS9013 NPN Transistors. Perfectly suited for amplification and switching applications, these transistors offer dependable functionality in a compact TO-92 package. Ideal for hobbyists and professional engineers alike, ensure efficient and reliable circuit performance every time.
Specifications:
- ✅ Quantity: 50 Pieces
- ✅ Type: NPN Bipolar Junction Transistor
- ✅ Package: TO-92
- ✅ Collector-Emitter Voltage (VCEO): 20V
- ✅ Collector Current (IC): 500mA
- ✅ Power Dissipation: 625mW
Features & Benefits:
- ✔️ Versatile for amplification and switching
- ✔️ Compact design for easy integration
- ✔️ High collector current capacity for robust operation
- ✔️ Reliable performance in various electronic applications
- ✔️ Suitable for professional and DIY projects
© 2025 Fahmah Jackson LLC. All Rights Reserved.
Specifications
| Brand | Unbranded |
|---|---|
| Continuous Collector Current | 500mA |
| Weight | 0.18g |
| Dimensions | 4.5mm x 4.1mm x 3.7mm |
| Number of Pins | 3 |
| Thermal Resistance | 200°C/W |
| Collector Current | 800mA |
| Emitter to Base Volts | 5V |
| Collector to Emitter Voltage | 20V |
| RoHS Compliant | Yes |
| Lead Free | Yes |
| Mounting Type | Through Hole |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -55°C |
| Collector Cut Off Current | 0.1uA |
| Part Number | SS9013 |
| Gain Bandwidth Product | 150 MHz |
| Base Emitter Saturation Voltage | 1.2V |
| Collector Capacitance | 8pF |
| Collector Emitter Saturation Voltage | 0.3V |
| Emitter Base Voltage | 5V |
| Collector Base Voltage | 30V |
| Transition Frequency (fT) | 150 MHz |
| DC Current Gain (hFE) | 64 - 210 |
| Power Dissipation | 625mW |
| IC | 500mA |
| VCEO | 20V |
| Package | TO-92 |
| Transistor Type | NPN |
