50pcs 2SC945 C945 NPN Transistor TO-92 40V 150mA 150mW
Out of stock
Out of stock
50pcs NPN Transistor TO-92
Enhance your electronic projects with our high-quality 50pcs 2SC945 NPN Transistor pack, ideal for efficient and reliable performance in a variety of applications.
- Voltage: 40V Maximum
- Current: 150mA Maximum Collector Current
- Package Type: TO-92
- Power Dissipation: 150mW
- Applications: Suitable for Amplification and Switching
Order now to take advantage of swift U.S. shipping and elevate your circuit designs with these versatile transistors.
Shipping, returns, and payments
50pcs 2SC945 C945 NPN Transistor TO-92 40V 150mA 150mW | US Ship
Product Details:
Enhance your electronic projects with the reliable 2SC945 C945 NPN transistors, ideal for amplification and switching applications. Boasting a robust TO-92 package, these transistors deliver consistent performance for both hobbyists and professionals in the electrical engineering field.
Specifications:
- Quantity: 50 Pieces
- Polarity: NPN
- Collector-Emitter Voltage (Vceo): 40V
- Collector Current (Ic): 150mA
- Power Dissipation: 150mW
- Package: TO-92
- Frequency: High-frequency applications
Features & Benefits:
- ✔️ Low noise for superior signal integrity
- ✔️ High gain for efficient amplification
- ✔️ Durable construction for long-lasting reliability
- ✔️ Versatile applications in audio and power circuits
- ✔️ Ideal for use in hobbyist projects and professional circuit designs
© 2025 Fahmah Jackson LLC. All Rights Reserved.
Specifications
| Brand | Unbranded |
|---|---|
| Pin Count | 3 |
| Country of Manufacture | China |
| Net Weight | 0.2g |
| Collector-Emitter Breakdown Voltage | 40V |
| Emitter-Base Reverse Voltage | 5V |
| Collector-Emitter Saturation Voltage | 0.3V |
| Noise Figure | 5dB |
| Gain Bandwidth Product | 150MHz |
| Polarity | Complementary |
| Halogen Free | Yes |
| RoHS Compliant | Yes |
| Lead Finish | Matte Tin |
| Configuration | Single |
| Mounting Style | Through Hole |
| Parameter | Value |
| Storage Temperature Range | -55°C to +150°C |
| Junction Temperature (Tj) | +150°C |
| Emitter Cut-off Current (Ieb) | 0.1μA |
| Collector Cut-off Current (Icb) | 0.1μA |
| DC Current Gain (hFE) | 70-700 |
| Transition Frequency (ft) | 150MHz |
| Power Dissipation (Pd) | 150mW |
| Collector Current (Ic) | 150mA |
| Emitter-Base Voltage (Vebo) | 5V |
| Collector-Base Voltage (Vcbo) | 60V |
| Collector-Emitter Voltage (Vceo) | 40V |
| Package Type | TO-92 |
| Type | NPN |
| Part Number | 2SC945 |
| MOQ (Minimum Order Quantity) | 50pcs |
