5 Pcs LM311P LM311 Differential Comparator DIP8
1 in stock
1 in stock
LM311P Comparator 5-Pack
Enhance your circuit design with our 5-pack LM311P Differential Comparators. Perfect for precision voltage comparison, these components deliver high-speed performance in a compact DIP8 package.
- Supply Voltage Range: 3.5V to 30V
- Output Current: 50 mA
- Package Type: DIP8
- Input Offset Voltage: 7.5 mV
- Applications: Voltage Sensing, Zero-Crossing Detection
Optimize your electronic projects with reliable and efficient LM311P Comparators. Order now to ensure precise voltage comparison in your designs.
Shipping, returns, and payments
5 Pcs LM311P LM311 Differential Comparator DIP8 | US Ship
Product Details:
Enhance your electronic projects with the reliable LM311P LM311 Differential Comparator in DIP8 package. Engineered for precision, these comparators are essential for creating differential signal processing applications. Their versatile nature allows seamless integration into a wide range of electronic devices where precise voltage comparison is critical.
Specifications:
- ✅ Quantity: 5 Pieces
- ✅ Package Type: DIP8
- ✅ Input Offset Voltage: 7.5mV (Max, at 25°C)
- ✅ Response Time: 200ns (Typical)
- ✅ Supply Voltage: ±15V
- ✅ Operating Temperature Range: 0°C to +70°C
- ✅ Application: Voltage Comparators, Pulse Generators, Signal Conditioning
Features & Benefits:
- ✔️ High-speed response for precise measurement
- ✔️ DIP8 package for easy breadboard prototyping
- ✔️ Wide supply voltage range for versatile use
- ✔️ Stable performance across specified temperature range
- ✔️ Ideal for switch-mode power supplies and sensor signal processing
© 2025 Fahmah Jackson LLC. All Rights Reserved.
Specifications
| Brand | Unbranded |
|---|---|
| Propagation Delay Time | 200 ns |
| Max Operating Voltage | 15 V |
| Min Operating Voltage | 5 V |
| Lead Shape | Predominantly Rectangular |
| Pin Count | 8 |
| Product Tier | Commercial |
| Temperature Coefficient | 1 µV/°C |
| RoHS Compliant | Yes |
| Mounting Type | Through Hole |
| High Level Output Voltage | 32 V |
| Low Level Output Voltage | 0.4 V |
| Power Dissipation | 500 mW |
| Junction Temperature | 150 °C |
| Gain Bandwidth Product | 4 MHz |
| Part Number | LM311P |
| Output Sink Current | 50 mA |
| Supply Current | 5.7 mA |
| Response Time | 200 ns |
| Input Bias Current | 250 nA |
| Input Offset Voltage | 7.5 mV |
| Operating Temperature Range | -40°C to +85°C |
| Supply Voltage (Max) | 32 V |
| Supply Voltage (Min) | 3.5 V |
| Output Type | Open Collector |
| Differential Input Voltage | ±30 V |
| Number of Comparators | 1 |
| Package | 8-PIN DIP |
| Description | Differential Comparator |
